MODEL SPEC.
Model
Cavity
Operating Pressure
( bar )
Proof Pressure
Flow
(l/min )
CV04-B20
SAE-04-2
240
350
5.7
CV04-20
Internal Leakage
(cc/min )
Installation Torque
( Nm )
Operating Temperature
Weight
( kg )
0.10
5.4 ~ 6.7
-40 ~ 120°C
( -40 ~ 248°F )
0.01
16 ~ 19
ORDER CODES
CV 04 - B 20 - N - 05
a b - c a - d - e
a. Model Name : CV-20
b. Valve Size : 04
c. Mounting :
B:down-hole mount
none:surface mount
d. Material of Seal :
N:buna-N
V:viton
E:EPDM
H:HNBR
U:polyurethane
e. Bias Spring :
05:0.34bar ( 5psi )
SYMBOLS
PERFORMANCE CURVES
Pressure Drop
DIMENSION (UNIT : mm)
