MODEL SPEC.
Model
Cavity
Operating Pressure
( bar )
Proof Pressure
Flow
(l/min )
FC10-20
SAE-10-2
240
345
45
Internal Leakage
(cc/min )
Installation Torque
( Nm )
Operating Temperature
Weight
( kg )
0.50
33.9
-40 ~ 120°C
( -40 ~ 248°F )
0.145
ORDER CODES
FC 10 A - 20 - N
a b c - a - d
a. Model Name : FC-20
b. Valve Size : 10
c. Adjustment Option :
A:1/4" Hex allen head
B:1 1/2" dia alum. knob
d. Material of Seal :
N:buna-N
V:viton
E:EPDM
H:HNBR
U:polyurethane
SYMBOLS
PERFORMANCE CURVES
Pressure Drop
DIMENSION (UNIT : mm)
