SV08
- 28G M - D1 - DR - N
a - b c -
d - e - f
a.
Valve Size : 08, 38, 10, 12
b. Model
: 28G, 28
c. Control
Manner :
none:without manual override
M:manual override *
d. Voltage
(coil) :
A1:115 VAC
A2:230 VAC
D1:12 VDC
D2:24 VDC
e. Connector
(coil) :
DG:DIN connector type
DL:wiring type
DR:Deutsch DT04-2P
f. Material
of Seal :
N:buna-N
V:viton
* Only for SV08-28GM
|
