MODEL SPEC.
Model
Max. Pressure
( kgf/cm2 )
Max. Flow
( l/min )
Weight
( kg )
MTCV-04
210
120
6
ORDER CODES
MTCV - 04 - W - I - 05
a - b - c - d - e
a. Model Name : MTCV
b. Thread Connection : 04: 1/2"
c. Action Form : A, B, W
d. Moving Direction :
none:out
I:in
e. Checking Pressure :
05:0.5 kgf/cm2
50:2.5 kgf/cm2
SYMBOLS
DIMENSION (UNIT : mm)
MTCV-04-A, B
MTCV-04-W
