MODEL SPEC.
Model
Max. Pressure
( kgf/cm2 )
Max. Flow
( l/min )
Weight
( kg )
MTCV-02
210
35
1.4
ORDER CODES
MTCV - 02 - W - I - 05
a - b - c - d - e
a. Model Name : MTCV
b. Thread Connection : 02: 1/4"
c. Action Form : A, B, W
d. Moving Direction :
none:out
I:in
e. Checking Pressure :
05:0.5 kgf/cm2
50:2.5 kgf/cm2
SYMBOLS
DIMENSION (UNIT : mm)
MTCV-02-A, B
MTCV-02-W
