RP2C
- T10A - LAN
a b - c - de f
a.
Model Name : RP
b. Valve
Size : 2C, 3C, 6C, 8C
c. Cavity
: T10A, T3A, T16A, T18A
d. Control
Manner :
L:standard screw adjustment
K:hand knob with lock knob
e. Adjustable
Range :
A:7~210 bar
B:3.5~105 bar
C:10.5~420 bar
N:5~55 bar
W:10.5~315 bar
f. Material
of Seal :
N:buna-N
V:viton
|
